Civil 170A 26.8V Portable IGBT Inverter Welder

Ask Lasest Price
Brand Name :	GENWELD
Model Number :	LWG-190
Certification :	CE
Price :	USD 45 Per Set
Payment Terms :	L/C, T/T
Supply Ability :	10000sets per month
Delivery Time :	15 work days

Add to Cart

Product Details
Company Profile

Civil 170A 26.8V Portable IGBT Inverter Welder

GENWELD MMA190 170A Portable Inverter ARC Welder

Features:

• The front panel is equipped with overheat-protection and over-current protection indicators. The current display is used to show the current data accurately. The acceptable input voltage range 130 - 260V.

• Three-layer PCB structure ensures the performance of the welding machine. Especially, the power supply board is more safe and stable.

• Hi-speed running fan with more optimized heat sink channel design, which makes the heat dissipation effect is 30% higher than the same type of inverter welding machine.

• Full bridge Inverter IGBT dual modules, large output voltage.

• Large capacitors are more flexible and support to connect with generator use.

• The whole series of products with hot arc starting, arc force, and anti-sticking functions. Easy to start the arc, low-pressure drop, comfortable operation.

• New dust-proof design, nice appearance, more cost-effective, more portable, and lighter.

Application field

• It’s widely used for many kinds of metal welding, like carbon steel, stainless, iron and etc.

Specification sheet

Model	MMA-190
Input voltage (V)	230V
Rated input power(KW)	6.5
Current range(A)	25-170(A)
Rated input current(A)	33
Efficiency %	85
Duty Cycle@40℃	60%	100%
Insulation Class	F	F
NO load Voltage(V)	65
Max. output current(A)	170	132
Max.output Voltage(V)	26.8	25.3
Max. output power(W)	4556	3339.6
Rated output current(A)	170	132
Rated output Voltage(V)	26.8	25.3
Electrode(mm)	2.5,3.2,4.0
Protection Class	IP23
Dimension(mm)	285120210
Net weight (kg)	3.7
Packing Dimension(mm)	320150240
Gross weight(kg)	6
Welding cable(m)	1.8
Power cable+Plug(m)	1.5
Ground cable(m)	1.2
