Portable 170A IGBT Mma Inverter Welder

Ask Lasest Price
Brand Name :	GENWELD
Model Number :	LW-G200A
Certification :	CE
Price :	90
Payment Terms :	L/C, T/T
Supply Ability :	10000 sets per month
Delivery Time :	20 work days

Add to Cart

Product Details
Company Profile

Portable 170A IGBT Mma Inverter Welder

GENWELD Portable 170A MMA & TIG IGBT Inverter Welder

Features:

• The front panel is equipped with overheat-protection and over-current protection indicators. The current display is used to show the current data accurately. The acceptable input voltage range 130 - 260V.

• Three-layer PCB structure ensures the performance of the welding machine. Especially, the power supply board is more safe and stable.

• Hi-speed running fan with more optimized heat sink channel design, which makes the heat dissipation effect is 30% higher than the same type of inverter welding machine.

• Full bridge Inverter IGBT dual modules, large output voltage.

• Large capacitors are more flexible and support to connect with generator use.

• The whole series of products with hot arc starting, arc force, and anti-sticking functions. Easy to start the arc, low-pressure drop, comfortable operation.

• New dust-proof design, nice appearance, more cost-effective, more portable, and lighter.

Application field

• It’s widely used for many kinds of metal welding, like carbon steel, stainless, iron and etc.

Specification sheet

Model	TIG200A
Input voltage (V)	AC220V
Rated input current(A)	MMA:34 / TIG:23
Current range(A)	MMA:20-165A TIG:15-175A
No load voltage(V)	65
Duty cycle@40℃	60%	100%
Max. output current(A)	MMA:165 TIG:175	MMA:128 TIG:135
Max.output Voltage(V)	MMA:26.6 TIG:17	MMA:25.1 TIG:15.4
Max. output power(W)	MMA:4389 TIG:2975	MMA:3212.8 TIG:2079
Rated output current(A)	MMA:165 TIG:175	MMA:128 TIG:135
Rated output Voltage(V)	MMA:26.6 TIG:17	MMA:25.1 TIG:15.4
Welding rod(mm)	Tungsten:φ1.0～3.0
Electrode(mm) for MMA	2.5/3.2
Insulation Class	F
Protection Class	IP23
Dimension (mm)	375150310
Net weight (kg)	6.4
Packing Dimension(mm)	450270345
Gross weight(kg)	9.1
TIG Gun(m)	QQ-150
Ground Cable+Clamp(m)	1.5(copper)
Power cable+Plug(m)	1.5
