Portable 4-In-1 Machine (Power generating, Air compressing, Welding, Lighting)

Ask Lasest Price
Brand Name :	GENWELD
Model Number :	LWGL200
Certification :	CE
Price :	USD 1200-1300 per set
Supply Ability :	1000 sets per month
Delivery Time :	30days

Add to Cart

Product Details
Company Profile

Portable 4-In-1 Machine (Power generating, Air compressing, Welding, Lighting)

GENWELD WAGL200 Portable 4-In-1 Machine

Introduction:

WAGL200 is a multi-function machine, it integrates welding, generating, air compressing, and lighting into one, can meet the needs of most civilian equipment maintenance. WAGL200 enjoys compact structure and light weight, it can easily move with 4-wheels. It is an ideal tool for civil equipment maintenance and municipal emergency rescue maintenance.

Features:

1. Multi-functions integration (welding,aircompressing,power generating, lighting) meet site construction/maintenance demand,

2. Stable and long time 5Kw AC output

3. Stable and reliable consistent work with 4.0mm welding rod.

4. Led 4x100M lights owns high brightness and low power consumption.

Application:

LWGL200 is widely used in field construction, municipal emergency,farm,ranch, ect.

LWGL200 Specifications Sheet

Generating section	Rated OCV(V)	220(AC)
	Rated power(kw)	5.0
	Max.power(kw)	5.5
	Rated current	22.7
Welding section	Duty cycle(%)	50%
	OCV(V)	75(DC)
	Current range(A)	DC 50-200
	Loaded voltage(V)	DC 22-28V
	Rated current/ voltage(A/V)	180A / 27.2V
Engine section	Engine model	SC420/CH440
	Max.power/Speed(RPM)	3600
	Displacement(CC)	420/ 429
	Start method	Electric
	Battery	12V/14Ah/Free maintenance
AIR COMPRESSOR	Capacity(L)	20.0
	Stage	1.0
	Flow	100L/min
	Pressure range	0.6-0.8Mpa
LIGHTS	Lights lift	4.5m
	Lights power	Led/4*100W
	Luminous flux	80-100lm/W
Whole set	Tank capacity(L)	30
	Protection class	IP23
	Outline size(mm)	850.5583780
	Carton packing size	860600800
	Net/gross weight(kg)	168.5kg
Start method:through drive
Generator:1.35KW/Single phase
Air compressor capacity:0.1m³/min
Pressure relief operation value:0.8 ±0.1
Pressure relief starting value:0.6 ±0.1
Safe valve operation value:0.9 ±0.1
Volume of Air Storage Tank:20L/double tanks
