LW-J160 Sheet Metal Intelligent Precision Cold Welding Machine
Introduction:
LW-J160 Sheet Metal Intelligent Precision Cold Welding Machineis a high-precision sheet metal welding machine dedicated to sheet
metal cod welding . The machine adopts CPU control to realize the
adjustment and storage of pulse voltage and time. The best welding
power can be achieved according to the actual situation of welding
defects, so that the welding raccuracy of the welding machine can
reach or even exceed the welding accuracy of the laser welding
machine, and at the same time it has the speed and flexibility of
argon welding. LW-J160 multifunctional cold welding machine adds
resistance wire feeding function on the basis of similar welding
machines, which can better adapt to complex-shaped workpieces and
speed up the repair speed. It is a cost-effective high-precision
intelligent welding machine that can reduce production costs for
enterprises.
Application areas:
Sheet metal welding, component welding, low temperature repair,
cold welding cladding.
Low temperature repair:
Molds, cast steel cast iron, stainless steel castings, shafts, high
chromium cast iron hydraulic rods, piston rods, etc.
Welding materials: conductive metals such as stainless steel, galvanized sheet, iron,
copper, aluminum, titanium alloy, nickel alloy, screen mesh, filter
mesh, etc.
Performance characteristics
1. Low temperature welding, precision repair welding, portable
resistance welding,
2. Multi-function can meet more demand from users,
3. Star model, fatigue resistance, 0.1mm starting welding,
4.32V/82000UF imported capacitors, high quality and reliable,
5. Operators without welding experience can also weld beautiful
products.
Equipment advantages
Welding
1. No deformation at low temperature without heat, the welding seam
is flat and smooth, and the welding point is white and not black;
2. There is no need for grinding and polishing after welding, which
saves production costs for enterprises;
3. The welding seam is beautiful and firm;
4. The welding seam has no interlayer and pores, and has good
sealing performance and can withstand high pressure.
Repair welding
1. No undercut, no collapse of corners, no pores;
2. Precise machining allowance and small heat affected zone;
3. Do not change the metallographic structure, solve the cracking
problem caused by internal stress;
4. High metallurgical bonding strength and can be machine-added;
5. Unrestricted surfacing height, strong applicability;
6. The welding repair flexibility is high, and it can be repaired
in 360 degrees without dead angles.
Specification sheet
| Device model | LW-J160 | Outline size | 420mm×220mm×325mm |
| Product weight | 22Kg | Control mode | CPU |
| Input voltage | 220V | Input power | 2200W |
| Mini current | 2A | Argon delay | 9S |
| Welding thickness | 0.1-0.3mm | Welding torch control method | Manual / Pedal |
| Cooling method | Air-cooling | Function choice | 1-4 |
|
Rectifier
mode | IGBT | Protection class | IP40 |
